This is  transport drone is ingeniously designed in terms of its body structure, adopting the concept of high strength and lightweight. Not only does it provide stable support for the body, but it also effectively reduces the overall weight. Further enhancing the body's impact resistance and durability. The power system, as the core of unmanned aerial vehicles, has a direct impact on their load capacity and flight performance.

　　Product parameters

　　Fuselage stmcture: 8*2=16 axes and 16rotors

　　Wingspan size:±3660mm*3660mm*1200mm

　　Folded size:± 1950mm*1950mm*1550mm

　　Net weight of bare metal: ≤88kg

　　Battery weight: ≤37Kg*2=74Kg

　　Take-off bare weight ≤162Kg

　　Battery capacity: ≥16 degrees /1 group

　　Charging time: ≤40 minutes

　　Discharge voltage: 60V-79.8V

　　Working environment temperature: -40℃-55℃

　　Endurance with empty aircraft: ≥ 50 minutes

　　Load endurance:≥18 minutes

　　Wind resistance level: 6 level

　　Waterproof rating:lP44

　　Maximum net pulling force: 240Kg

　　Maximum take-off weight:≤402kg

　　Maximum control distance: 50km

　　Maximum lifting speed: ±8m/s

　　Maximum horizontal speed:±25m/s

　　Maximum operating altitude: 5500m

　　Modular design

　　Easier maintenance and maintenance

　　Carbon fiber with aerospace aluminum alloy

　　Lightweight, more robust and easy to operate

　　Foldable

　　It is convenient and fast to disassemble and transport

　　Redundant design

　　Higher stability and fault tolerance

　　*(Product parameters are for reference only, please refer to the actual product)
